Commencal Meta Power SX Bosch Metallic Green Enduro Mountain E-Bike
Frame
META POWER SX BOSCH, 165 mm travel
29"-27.5", Alloy 6066, triple butted tubes, T4, T6.Motor
BOSCH Performance Line CX
Max. torque: 85N.m, 250WBattery
BOSCH PowerTube 625, 625Wh
BOSCH 4A Charger, Compact size & lightweight
Compatible w/Bosch PowerMore 250 for extra rangeDisplay
BOSCH System Controller
BOSCH Mini Remote currently not available in the USAShock
ROCKSHOX Deluxe Select
230 x 65 mm, R damper, DebonAir, rebound, 1 Token neg. 4 Tokens pos.Fork
ROCKSHOX Domain RC, 170 mm travel
29'', Motion Control damper, DebonAir, rebound, LSC, Boost (15 x 110 mm), 44 mm offset, 1 TokenHeadset
ACROS ZS56 / ZS66
Alloy cups, sealed bearingsStem
RIDE ALPHA 40 EXTERNAL
40 mm extension, 31,8 mmHandlebar
RIDE ALPHA R20 POWER on S - RIDE ALPHA R27 POWER on M / L / XL
Internal Di2 cable routing - 31.8 mm, 760 mm width, 20 mm rise, Alloy 6061 on S - 31.8 mm, 780 mm width, 27 mm rise, Alloy 6061 on M / L - 31.8 mm, 800 mm width, 27 mm rise, Alloy 6061 on XLGrips
ODI Elite Motion
Soft pro compound, single clamp, blackBrakes
SRAM Guide RE, 4 pistons, steel-backed metal sintered pads
Rotors: SRAM HS2 220 mm, 6-boltShifters
SRAM SX Eagle
12sChain guide
RIDE ALPHA Upper Guide
32-34tREAR DERAILLEUR
SRAM SX Eagle
12sBottom bracket
BOSCH
Crankset
E13 E*Spec Plus BOSCH CX, 160 mm crank arms
Chainring: E13 E*Spec Plus BOSCH CX, 34t, direct mountChain
SRAM NX Eagle
12sCassette
SRAM PG-1210
12s, 11-50tRims
Rear: SPANK Spike Race 33 - Front: SPANK Spike Race 33
Rear: 27.5'', 32h, 28 mm inner width rear - Front: 29'', 32h, 28 mm inner width frontHubs
Rear: FORMULA eHL-148S - Front: FORMULA DC-711
Rear: 32h, 12 x 148 mm, sealed bearings, e-bike specific, SHIMANO Hyperglide - Front: 32h, 15 x 110 mm, sealed bearingsSpokes/nipples
SAPIM Strong
J-Bend, 2.34/2.0mm, double butted, stainless, with Nylok, blackTyres
Rear: MAXXIS DHR II - Front: MAXXIS Assegai
Rear: 27.5" x 2.4" WT, 3C Maxx Terra, Double Down, Tubeless Ready - Front: 29" x 2.5" WT, 3C Maxx Grip, Exo+, Tubeless ReadySeat post
KS Rage I
31.6 mm, travel: 125 mm on S, 170 mm on M/L, 190 mm on XL, SouthPaw alloy remoteSaddle
FIZIK Terra Aidon X5
145 mm width, S-Alloy Mobius railsWeight
25 kg / 55.1 lbs
Average weight for S size, without pedals. Weight may differ slightly due to manufacturing tolerances.Pedals included
Yes
Colour
Metallic Green
Matte FinishAccessories
RIDE ALPHA CNC pedals, fork fender, motor protector, chainstay protector, seatstay protector, user manual
*Actual product may differ from pictures.
*Please note that bike specs are subject to change without prior notice.Battery recycling
Partnership with BOSCH
The battery (used up, damaged, defective) must be recycled. Each national distributor is responsible for providing the dealer with a free recycling solution.
Applicable laws: Battery Act, Directive 2006/66/EC, BattG in Germany too.
Robert Bosch GmbH recommends concluding a contract with a national service provider for returning batteries in each case.
Bicycle type
E-BIKE ENDURO 29''/27''
Frame material
AL 6066 T4, T6
Frame weight
- kg / - lb - With plastic accessories.
Rear travel
165 mm
Shock length/stroke
230 x 65 mm
Piggy back shock compatible
Yes
Shock bushings
20 x 10 mm front
Recommended/max. fork height
583 mm / 593 mm
Headset dimension
Tapered
Headset type
ZS56 / ZS66
Maximum tyre dimension (etrto)
65 - 584 mm
Disc brake standard
PM160
Rear rotor max. size
220 mm
Seatpost/seat clamp diameter
31,6 mm / 34,9 mm
Bottom bracket type
BOSCH E-BIKE
ISCG
Yes (BOSCH Standard)
Rear hub compatibility
12 x 148 mm
Frame
META POWER SX BOSCH, 165 mm travel
29"-27.5", Alloy 6066, triple butted tubes, T4, T6.Motor
BOSCH Performance Line CX
Max. torque: 85N.m, 250WBattery
BOSCH PowerTube 625, 625Wh
BOSCH 4A Charger, Compact size & lightweight
Compatible w/Bosch PowerMore 250 for extra rangeDisplay
BOSCH System Controller
BOSCH Mini Remote currently not available in the USAShock
ROCKSHOX Deluxe Select
230 x 65 mm, R damper, DebonAir, rebound, 1 Token neg. 4 Tokens pos.Fork
ROCKSHOX Domain RC, 170 mm travel
29'', Motion Control damper, DebonAir, rebound, LSC, Boost (15 x 110 mm), 44 mm offset, 1 TokenHeadset
ACROS ZS56 / ZS66
Alloy cups, sealed bearingsStem
RIDE ALPHA 40 EXTERNAL
40 mm extension, 31,8 mmHandlebar
RIDE ALPHA R20 POWER on S - RIDE ALPHA R27 POWER on M / L / XL
Internal Di2 cable routing - 31.8 mm, 760 mm width, 20 mm rise, Alloy 6061 on S - 31.8 mm, 780 mm width, 27 mm rise, Alloy 6061 on M / L - 31.8 mm, 800 mm width, 27 mm rise, Alloy 6061 on XLGrips
ODI Elite Motion
Soft pro compound, single clamp, blackBrakes
SRAM Guide RE, 4 pistons, steel-backed metal sintered pads
Rotors: SRAM HS2 220 mm, 6-boltShifters
SRAM SX Eagle
12sChain guide
RIDE ALPHA Upper Guide
32-34tREAR DERAILLEUR
SRAM SX Eagle
12sBottom bracket
BOSCH
Crankset
E13 E*Spec Plus BOSCH CX, 160 mm crank arms
Chainring: E13 E*Spec Plus BOSCH CX, 34t, direct mountChain
SRAM NX Eagle
12sCassette
SRAM PG-1210
12s, 11-50tRims
Rear: SPANK Spike Race 33 - Front: SPANK Spike Race 33
Rear: 27.5'', 32h, 28 mm inner width rear - Front: 29'', 32h, 28 mm inner width frontHubs
Rear: FORMULA eHL-148S - Front: FORMULA DC-711
Rear: 32h, 12 x 148 mm, sealed bearings, e-bike specific, SHIMANO Hyperglide - Front: 32h, 15 x 110 mm, sealed bearingsSpokes/nipples
SAPIM Strong
J-Bend, 2.34/2.0mm, double butted, stainless, with Nylok, blackTyres
Rear: MAXXIS DHR II - Front: MAXXIS Assegai
Rear: 27.5" x 2.4" WT, 3C Maxx Terra, Double Down, Tubeless Ready - Front: 29" x 2.5" WT, 3C Maxx Grip, Exo+, Tubeless ReadySeat post
KS Rage I
31.6 mm, travel: 125 mm on S, 170 mm on M/L, 190 mm on XL, SouthPaw alloy remoteSaddle
FIZIK Terra Aidon X5
145 mm width, S-Alloy Mobius railsWeight
25 kg / 55.1 lbs
Average weight for S size, without pedals. Weight may differ slightly due to manufacturing tolerances.Pedals included
Yes
Colour
Metallic Green
Matte FinishAccessories
RIDE ALPHA CNC pedals, fork fender, motor protector, chainstay protector, seatstay protector, user manual
*Actual product may differ from pictures.
*Please note that bike specs are subject to change without prior notice.Battery recycling
Partnership with BOSCH
The battery (used up, damaged, defective) must be recycled. Each national distributor is responsible for providing the dealer with a free recycling solution.
Applicable laws: Battery Act, Directive 2006/66/EC, BattG in Germany too.
Robert Bosch GmbH recommends concluding a contract with a national service provider for returning batteries in each case.
Bicycle type
E-BIKE ENDURO 29''/27''
Frame material
AL 6066 T4, T6
Frame weight
- kg / - lb - With plastic accessories.
Rear travel
165 mm
Shock length/stroke
230 x 65 mm
Piggy back shock compatible
Yes
Shock bushings
20 x 10 mm front
Recommended/max. fork height
583 mm / 593 mm
Headset dimension
Tapered
Headset type
ZS56 / ZS66
Maximum tyre dimension (etrto)
65 - 584 mm
Disc brake standard
PM160
Rear rotor max. size
220 mm
Seatpost/seat clamp diameter
31,6 mm / 34,9 mm
Bottom bracket type
BOSCH E-BIKE
ISCG
Yes (BOSCH Standard)
Rear hub compatibility
12 x 148 mm
This beast runs on a BOSCH Performance Line CX motor with a 625Wh PowerTube battery and RockShox suspension delivering 170mm up front and 165mm rear travel. The alloy frame rolls on SPANK Race 33 rims with Maxxis Minion tyres for serious traction. SRAM SX Eagle 12-speed shifting and Guide RE 4-piston brakes bring the control. With a KS dropper, ODI grips, and FIZIK saddle, it’s built for rowdy rides, steep climbs, and everything the trail dares to throw your way.
The META POWER SX BOSCH is a full-blooded enduro e-bike frame built from AL 6066 T4/T6 alloy and tuned for serious terrain. It delivers 165mm of rear travel, handles piggyback shocks with ease, and supports a 230x65mm stroke. With a tapered ZS56/ZS66 headset, PM160 brake mount, 220mm rear rotor compatibility, and Bosch E-Bike bottom bracket, it’s built for control and punishment. Mullet-ready, ISCG-equipped, and hub-spaced at 12 x 148mm—it’s a chassis that means business from the first descent.
