Commencal META SX V5 Race Sparkly Blue Enduro Bike
Frame
META SX V5, 165 mm travel
29''-27.5'', Alloy 6066, triple butted tubes, T4, T6Shock
ROCKSHOX Super Deluxe Ultimate
230 x 65 mm, RC2T damper, DebonAir, HSC, LSC, rebound, 2-position (open/firm) compression, 0 Token neg. 2 Tokens pos.Fork
ROCKSHOX Zeb Ultimate, 170 mm travel
29", Charger 3 RC2 W/ButterCup damper, DebonAir+ W/ButterCups, LSC, HSC, rebound, Boost (15 x 110 mm), 44 mm offset, 1 TokenHeadset
ACROS ZS56 / ZS56
Alloy cups, sealed bearingsStem
RIDE ALPHA 40
40 mm extension, 31,8 mmHandlebar
RIDE ALPHA R20 760 on S - RIDE ALPHA R27 780 on M / L - RIDE ALPHA R27 800 on XL
31.8 mm, 760 mm width, 20 mm rise, Alloy 6061 on S - 31.8 mm, 780 mm width, 27 mm rise, Alloy 6061 on M / L - 31.8 mm, 800 mm width, 27 mm rise, Alloy 6061 on XLGrips
ODI Longneck
Soft compound, single clamp, blackBrakes
TRP DH-R EVO, 4 pistons, resin pads, Postmount
Rotors: TRP R1 203 mm, 6-bolts, 2.3 mm widthShifters
SRAM GX Eagle
12sChain guide
RIDE ALPHA
32t-34tREAR DERAILLEUR
SRAM GX Eagle
12sBottom bracket
SRAM DUB WIDE
PressfitCrankset
SRAM GX Eagle, 165 mm crank arms, DUB, Boost
Chainring: SRAM GX Eagle, 32t, Narrow-WideChain
SRAM GX Eagle
12sCassette
SRAM XG-1275 Eagle
12s, 10-52tRims
CRANK BROTHERS Synthesis Alloy Enduro 3
Rear: 27,5'', 32h, 29.5 mm inner width - Front: 29'', 28h, 31.5 mm inner widthHubs
INDUSTRY NINE 1/1
Rear: 32h, sealed bearings, 12 x 148 mm, 4°, XD driver, black - Front: 28h, sealed bearings, 15 x 110 mm, blackSpokes/nipples
Rear: SAPIM Race - Front: SAPIM D-Light
Rear: J-Bend, 2.0-1.8-2.0mm, double butted, stainless, with Nylok, black - Front: J-Bend, 2.0-1.65-2.0mm, double butted, stainless, with Nylok, blackTyres
Rear: MAXXIS DHR II - Front: MAXXIS Assegai
Rear: 27.5"x2.4" WT, 3C MaxxTerra, EXO+, Tubeless Ready - Front: 29"x2.5" WT, 3C MaxxTerra, EXO, Tubeless ReadySeat post
KS Lev Integra
34.9 mm, travel: 125 mm on S, 175 mm on M/L and 200 mm on XL, SouthPaw alloy remoteSaddle
SDG Bel Air V3 Atmos
140 mm width, Lux-Alloy RailsWeight
15.9 kg / 35 lbs
Average weight for S size, without pedals. Weight may differ slightly due to manufacturing tolerances.Pedals included
No
Colour
Sparkly Blue
Matte FinishAccessories
Down tube protector, chainstay protector, seatstay protector, pick up pad, fork fender
*Please note that bike specs are subject to change without prior notice.
Bicycle type
ENDURO 27/29"
Frame material
AL 6066 T4, T6
Frame weight
3,3 kg / 7.27 lb, raw without accessories
Rear travel
165 mm
Shock length/stroke
230 x 65 mm
Piggy back shock compatible
Yes
Shock bushings
NOTHING ON BODY / 20 X 10 mm ON SHAFT
Recommended/max. fork height
586 mm / 44 mm
Headset type
ZS56 / ZS56, Integrated cable routing
Maximum tyre dimension (etrto)
64 mm / diam. 721
Disc brake standard
Postmount 200 mm
Rear rotor max. size
223 mm
Seatpost/seat clamp diameter
34,9 mm / 38,6 mm
Bottom bracket type
Press Fit BB 92
ISCG
ISCG 05
Chain Line
55 mm
Rear hub compatibility
L=180 mm, M12, P1.0 mm - Hub 12 x 148 mm standard maxle


Frame
META SX V5, 165 mm travel
29''-27.5'', Alloy 6066, triple butted tubes, T4, T6Shock
ROCKSHOX Super Deluxe Ultimate
230 x 65 mm, RC2T damper, DebonAir, HSC, LSC, rebound, 2-position (open/firm) compression, 0 Token neg. 2 Tokens pos.Fork
ROCKSHOX Zeb Ultimate, 170 mm travel
29", Charger 3 RC2 W/ButterCup damper, DebonAir+ W/ButterCups, LSC, HSC, rebound, Boost (15 x 110 mm), 44 mm offset, 1 TokenHeadset
ACROS ZS56 / ZS56
Alloy cups, sealed bearingsStem
RIDE ALPHA 40
40 mm extension, 31,8 mmHandlebar
RIDE ALPHA R20 760 on S - RIDE ALPHA R27 780 on M / L - RIDE ALPHA R27 800 on XL
31.8 mm, 760 mm width, 20 mm rise, Alloy 6061 on S - 31.8 mm, 780 mm width, 27 mm rise, Alloy 6061 on M / L - 31.8 mm, 800 mm width, 27 mm rise, Alloy 6061 on XLGrips
ODI Longneck
Soft compound, single clamp, blackBrakes
TRP DH-R EVO, 4 pistons, resin pads, Postmount
Rotors: TRP R1 203 mm, 6-bolts, 2.3 mm widthShifters
SRAM GX Eagle
12sChain guide
RIDE ALPHA
32t-34tREAR DERAILLEUR
SRAM GX Eagle
12sBottom bracket
SRAM DUB WIDE
PressfitCrankset
SRAM GX Eagle, 165 mm crank arms, DUB, Boost
Chainring: SRAM GX Eagle, 32t, Narrow-WideChain
SRAM GX Eagle
12sCassette
SRAM XG-1275 Eagle
12s, 10-52tRims
CRANK BROTHERS Synthesis Alloy Enduro 3
Rear: 27,5'', 32h, 29.5 mm inner width - Front: 29'', 28h, 31.5 mm inner widthHubs
INDUSTRY NINE 1/1
Rear: 32h, sealed bearings, 12 x 148 mm, 4°, XD driver, black - Front: 28h, sealed bearings, 15 x 110 mm, blackSpokes/nipples
Rear: SAPIM Race - Front: SAPIM D-Light
Rear: J-Bend, 2.0-1.8-2.0mm, double butted, stainless, with Nylok, black - Front: J-Bend, 2.0-1.65-2.0mm, double butted, stainless, with Nylok, blackTyres
Rear: MAXXIS DHR II - Front: MAXXIS Assegai
Rear: 27.5"x2.4" WT, 3C MaxxTerra, EXO+, Tubeless Ready - Front: 29"x2.5" WT, 3C MaxxTerra, EXO, Tubeless ReadySeat post
KS Lev Integra
34.9 mm, travel: 125 mm on S, 175 mm on M/L and 200 mm on XL, SouthPaw alloy remoteSaddle
SDG Bel Air V3 Atmos
140 mm width, Lux-Alloy RailsWeight
15.9 kg / 35 lbs
Average weight for S size, without pedals. Weight may differ slightly due to manufacturing tolerances.Pedals included
No
Colour
Sparkly Blue
Matte FinishAccessories
Down tube protector, chainstay protector, seatstay protector, pick up pad, fork fender
*Please note that bike specs are subject to change without prior notice.
Bicycle type
ENDURO 27/29"
Frame material
AL 6066 T4, T6
Frame weight
3,3 kg / 7.27 lb, raw without accessories
Rear travel
165 mm
Shock length/stroke
230 x 65 mm
Piggy back shock compatible
Yes
Shock bushings
NOTHING ON BODY / 20 X 10 mm ON SHAFT
Recommended/max. fork height
586 mm / 44 mm
Headset type
ZS56 / ZS56, Integrated cable routing
Maximum tyre dimension (etrto)
64 mm / diam. 721
Disc brake standard
Postmount 200 mm
Rear rotor max. size
223 mm
Seatpost/seat clamp diameter
34,9 mm / 38,6 mm
Bottom bracket type
Press Fit BB 92
ISCG
ISCG 05
Chain Line
55 mm
Rear hub compatibility
L=180 mm, M12, P1.0 mm - Hub 12 x 148 mm standard maxle



The COMMENCAL META SX V5 RACE features a 165mm travel alloy frame paired with a RockShox Zeb Ultimate fork and Super Deluxe Ultimate shock for big-hit control and plush tracking. TRP DH-R Evo brakes and SRAM GX Eagle 12-speed drivetrain bring serious enduro capability, while Crankbrothers Synthesis Enduro wheels (29” front, 27.5” rear) with Industry Nine 1/1 hubs deliver strength and precision. Maxxis Assegai and DHR II tyres, a KS Lev dropper, and SDG Bel Air saddle round out this ready-to-rumble Kiwi trail crusher.
Built for serious enduro abuse, the META SX V5 frame runs a mullet setup (29” front, 27.5” rear) with 165mm of plush rear travel and a lightweight AL 6066 T4/T6 alloy chassis tipping the scales at just 3.3kg raw. It’s fully piggy-back compatible, runs a 230x65mm shock, and handles a max 223mm rear rotor for big braking power. Integrated cable routing, ISCG 05 tabs, BB92 press-fit bottom bracket, and 55mm chain line round out a dialled-in platform that’s ready to get rowdy.
