Commencal Supreme DH V5 Öhlins Edition Metallic Green Downhill Bike
Frame
SUPREME DH V5 29/27, 220 mm travel on S / M / L / XL
27/29'', Alloy 6066, triple butted tubes, T4, T6Shock
OHLINS TTX22 m.2
250 x 75 mm, HSC, LSC, rebound. Spring rates: 388 lbs on S, 434 lbs on M, 457 lbs on L, 502 lbs on XLFork
OHLINS DH38 m.1 Air, 200 mm travel
29", TTX 18 damper, LSC, HSC, rebound, Boost (20 x 110 mm), 54 mm offsetHeadset
ACROS ZS56 / ZS56
Alloy cups, sealed bearingsStem
RIDE ALPHA DH 40
40 mm extension, direct mount, 31.8 mmHandlebar
RIDE ALPHA R27
31.8 mm, 780 mm width, 27 mm rise, Alloy 6061 on S / M / L - 31.8 mm, 800 mm width, 27 mm rise, Alloy 6061 on XLGrips
ODI Elite Motion
Soft pro compound, single clamp, blackBrakes
TRP DH-R Evo, 4 pistons, resin pads
Rotors : TRP R1 223 mm, 6-bolt, 2.3 mm thicknessShifters
SRAM GX DH
7 spChain guide
E13 LG1 + Bottom Guide
32-34tREAR DERAILLEUR
SRAM GX DH
7 spBottom bracket
SRAM DUB
PressfitCrankset
TRUVATIV Descendant DH, 165 mm crank arms, DUB
Chainring: TRUVATIV Descendant DH X-Sync, 34tChain
KMC X11EL
BlackCassette
SRAM PG-720
7s, 11-25tRims
DT SWISS FR560
Rear: 27.5'', 32h, 30 mm inner width - Front: 29'', 32h, 30 mm inner widthHubs
Rear: DT SWISS 350 - Front: DT SWISS 350
Rear: 32h, sealed bearings, 12 x 157 mm, Shimano Hyperglide, black - Front: 32h, sealed bearings, 20 x 110 mm Boost, blackSpokes/nipples
DT SWISS Competition
J-Bend, 2.0-1.8-2.0mm, double butted, stainless, with ProLock, blackTyres
Rear: SCHWALBE Magic Mary - Front: SCHWALBE Magic Mary
Rear: 27.5'' x 2.4'', Super DH, Addix Ultra Soft - Front: 29" x 2.4", Super DH, Addix Ultra SoftSeat post
RIDE ALPHA Super Light
31.6 mm, 250 mm lengthSaddle
FIZIK Gravita Alpaca X5
130 mm width, S-Alloy railsWeight
18,4 kg / 40,56 lbs
Average weight for S size, without pedals. Weight may differ slightly due to manufacturing tolerances.Pedals included
No
Colour
Metallic Green
Matte FinishAccessories
Chainstay protector, seatstay protector, downtube protector, roller cover, frame mudguard
*Please note that bike specs are subject to change without prior notice.
Bicycle type
DH 29''/27''
Frame material
AL 6066 T4, T6
Frame weight
5,4 kg / 11,9 lbs in size S with frame protections, chain guide, rear wheel axle
Rear travel
220 mm
Shock length/stroke
250 x 75
Piggy back shock compatible
Yes
Shock bushings
20 x 10 mm / 30 x 8 mm
Recommended/max. fork height
630 mm / 638 mm
Headset type
ZS56 / ZS56
Maximum tyre dimension (etrto)
64 mm / diam 721
Disc brake standard
Postmount 200 mm
Rear rotor max. size
223 mm
Seatpost/seat clamp diameter
31,6 mm / 34,9 mm
Bottom bracket type
Press Fit BB 107
ISCG
ISCG 05
Rear hub compatibility
L=200 mm, M12, P1.0 mm - Hub 157 x 12 mm standard Maxle
Flip Chip
Front / Up - Rear / Low (Available as an option: Front / Low - Rear / Up)Wheel Base Length
Centered (Available as an option: Flip Flop +/-6mm)Bridge
XS & S: Thin - M & L: Medium - XL: Thick (All bridges are available as an option)
Frame
SUPREME DH V5 29/27, 220 mm travel on S / M / L / XL
27/29'', Alloy 6066, triple butted tubes, T4, T6Shock
OHLINS TTX22 m.2
250 x 75 mm, HSC, LSC, rebound. Spring rates: 388 lbs on S, 434 lbs on M, 457 lbs on L, 502 lbs on XLFork
OHLINS DH38 m.1 Air, 200 mm travel
29", TTX 18 damper, LSC, HSC, rebound, Boost (20 x 110 mm), 54 mm offsetHeadset
ACROS ZS56 / ZS56
Alloy cups, sealed bearingsStem
RIDE ALPHA DH 40
40 mm extension, direct mount, 31.8 mmHandlebar
RIDE ALPHA R27
31.8 mm, 780 mm width, 27 mm rise, Alloy 6061 on S / M / L - 31.8 mm, 800 mm width, 27 mm rise, Alloy 6061 on XLGrips
ODI Elite Motion
Soft pro compound, single clamp, blackBrakes
TRP DH-R Evo, 4 pistons, resin pads
Rotors : TRP R1 223 mm, 6-bolt, 2.3 mm thicknessShifters
SRAM GX DH
7 spChain guide
E13 LG1 + Bottom Guide
32-34tREAR DERAILLEUR
SRAM GX DH
7 spBottom bracket
SRAM DUB
PressfitCrankset
TRUVATIV Descendant DH, 165 mm crank arms, DUB
Chainring: TRUVATIV Descendant DH X-Sync, 34tChain
KMC X11EL
BlackCassette
SRAM PG-720
7s, 11-25tRims
DT SWISS FR560
Rear: 27.5'', 32h, 30 mm inner width - Front: 29'', 32h, 30 mm inner widthHubs
Rear: DT SWISS 350 - Front: DT SWISS 350
Rear: 32h, sealed bearings, 12 x 157 mm, Shimano Hyperglide, black - Front: 32h, sealed bearings, 20 x 110 mm Boost, blackSpokes/nipples
DT SWISS Competition
J-Bend, 2.0-1.8-2.0mm, double butted, stainless, with ProLock, blackTyres
Rear: SCHWALBE Magic Mary - Front: SCHWALBE Magic Mary
Rear: 27.5'' x 2.4'', Super DH, Addix Ultra Soft - Front: 29" x 2.4", Super DH, Addix Ultra SoftSeat post
RIDE ALPHA Super Light
31.6 mm, 250 mm lengthSaddle
FIZIK Gravita Alpaca X5
130 mm width, S-Alloy railsWeight
18,4 kg / 40,56 lbs
Average weight for S size, without pedals. Weight may differ slightly due to manufacturing tolerances.Pedals included
No
Colour
Metallic Green
Matte FinishAccessories
Chainstay protector, seatstay protector, downtube protector, roller cover, frame mudguard
*Please note that bike specs are subject to change without prior notice.
Bicycle type
DH 29''/27''
Frame material
AL 6066 T4, T6
Frame weight
5,4 kg / 11,9 lbs in size S with frame protections, chain guide, rear wheel axle
Rear travel
220 mm
Shock length/stroke
250 x 75
Piggy back shock compatible
Yes
Shock bushings
20 x 10 mm / 30 x 8 mm
Recommended/max. fork height
630 mm / 638 mm
Headset type
ZS56 / ZS56
Maximum tyre dimension (etrto)
64 mm / diam 721
Disc brake standard
Postmount 200 mm
Rear rotor max. size
223 mm
Seatpost/seat clamp diameter
31,6 mm / 34,9 mm
Bottom bracket type
Press Fit BB 107
ISCG
ISCG 05
Rear hub compatibility
L=200 mm, M12, P1.0 mm - Hub 157 x 12 mm standard Maxle
Flip Chip
Front / Up - Rear / Low (Available as an option: Front / Low - Rear / Up)Wheel Base Length
Centered (Available as an option: Flip Flop +/-6mm)Bridge
XS & S: Thin - M & L: Medium - XL: Thick (All bridges are available as an option)
This Metallic Green DH beast is loaded with pro-spec gear: ÖHLINS DH38 m.1 Air fork and TTX22m.2 coil shock deliver race-calibrated suspension. TRP DH-R Evo brakes with 223mm rotors mean business on the descents. DT SWISS FR560 rims, Magic Mary tyres, and SRAM GX DH 7-speed drivetrain keep you charging hard. RIDE ALPHA finishing kit and a FIZIK Gravita saddle round out the build. At 18.4kg, it’s all muscle, no fluff—built to dominate trails, podiums, and anything in between.
Engineered for downhill dominance, this frame combines a mixed-wheel 29"/27" setup with a burly 220mm of rear travel for full-send confidence. The AL 6066 T4/T6 construction weighs in at 5.4kg (size S, with protection), while the geometry is fully tunable thanks to flip chips and optional bridge sizes. Designed for big forks (up to 638mm), 223mm rear rotors, and piggyback shocks, it’s built for high-speed punishment. Add in ISCG 05 tabs and a 157x12 rear axle, and you’ve got pure DH pedigree.
