Commencal Supreme DH V5 Signature Clear Silver Downhill Bike
Frame
SUPREME DH V5 29/27, 220 mm travel on S / M / L / XL
27/29'', Alloy 6066, triple butted tubes, T4, T6Shock
FOX FLOAT X2 Factory
250 x 75 mm, HSC, LSC, HSR, LSR, 0.3 spacer x3Fork
FOX 40 Factory, 203 mm travel
29", Grip2 damper, HSC, LSC, HSR, LSR. Boost (20 x 110 mm), 52 mm offset, 2 spacers.Headset
ACROS ZS56 / ZS56
Alloy cups, sealed bearingsStem
RIDE ALPHA DH 40
40 mm extension, direct mount, 31.8 mmHandlebar
RIDE ALPHA R27
31.8 mm, 780 mm width, 27 mm rise, Alloy 6061 on S / M / L - 31.8 mm, 800 mm width, 27 mm rise, Alloy 6061 on XLGrips
ODI Longneck
Soft pro compound, single clamp, blackBrakes
TRP DH-R Evo, 4 pistons, resin pads
Rotors: TRP R1 223 mm, 6-bolt, 2.3 mm widthShifters
SRAM GX DH
7 spChain guide
E13 LG1 + Bottom Guide
32-34tREAR DERAILLEUR
SRAM GX DH
7 spBottom bracket
SRAM DUB
PressfitCrankset
TRUVATIV Descendant DH, 165 mm crank arms, DUB
Chainring: TRUVATIV Descendant DH X-Sync, 34tChain
KMC X11EL
BlackCassette
E13 DH 7 Speed Integrated Cassette
7 sp, 9-24tRims
E13 GRAPPLER Race Alloy
Rear: 27.5'', 32h, 30 mm inner width - Front: 29'', 32h, 30 mm inner widthHubs
Rear: E13 GRAPPLER Race Alloy - Front: E13 GRAPPLER Race Alloy
Rear: 32h, sealed bearings, 12 x 157 mm, black - Front: 32h, sealed bearings, 20 x 110 mm Boost, blackTyres
Rear: SCHWALBE TACKY CHAN - Front: SCHWALBE TACKY CHAN
Rear: 27.5''x2.4'', Super DH, Addix Ultra Soft, Tubeless Easy - Front: 29"x2.4", Super DH, Addix Ultra Soft, Tubeless EasySeat post
RIDE ALPHA Super Light
31.6 mm, 250 mm, Alloy 7075Saddle
FIZIK Gravita Alpaca X5
130 mm width, S-Alloy railsWeight
18,1 kg / 39,9 lbs
Average weight for S size, without pedals. Weight may differ slightly due to manufacturing tolerances.Pedals included
No
Colour
Clear Silver
Shiny FinishAccessories
Chainstay protector, seatstay protector, downtube protector, roller cover, frame mudguard, tubeless valves, fork fender specific Fox 40
*Please note that bike specs are subject to change without prior notice
Bicycle type
Frame DH Racing
Frame material
Al 6066 T4, T6
Frame weight
5,3 kg / 11,68 lbs in size S with frame protections, chain guide, rear wheel axle
Rear travel
220 mm
Shock length/stroke
250 mm / 75 mm
Piggy back shock compatible
Yes
Shock bushings
30 x 8 mm / 30 x 8 mm
Recommended/max. fork height
612 mm / 620 mm
Headset type
ZS56 / ZS56
Maximum tyre dimension (etrto)
65 mm
Disc brake standard
Postmount 200 mm
Rear rotor max. size
223 mm
Seatpost/seat clamp diameter
31,6 mm / 34,9 mm
Bottom bracket type
Press Fit BB 107
ISCG
ISCG 05
Rear hub compatibility
L=200 mm, M12, P1.0 mm - Hub 157 x 12 mm standard Maxle
Flip Chip
Front / UpWheel Base Length
CenteredBridge
XS & S : Thin - M & L : Medium - XL : Thick


Frame
SUPREME DH V5 29/27, 220 mm travel on S / M / L / XL
27/29'', Alloy 6066, triple butted tubes, T4, T6Shock
FOX FLOAT X2 Factory
250 x 75 mm, HSC, LSC, HSR, LSR, 0.3 spacer x3Fork
FOX 40 Factory, 203 mm travel
29", Grip2 damper, HSC, LSC, HSR, LSR. Boost (20 x 110 mm), 52 mm offset, 2 spacers.Headset
ACROS ZS56 / ZS56
Alloy cups, sealed bearingsStem
RIDE ALPHA DH 40
40 mm extension, direct mount, 31.8 mmHandlebar
RIDE ALPHA R27
31.8 mm, 780 mm width, 27 mm rise, Alloy 6061 on S / M / L - 31.8 mm, 800 mm width, 27 mm rise, Alloy 6061 on XLGrips
ODI Longneck
Soft pro compound, single clamp, blackBrakes
TRP DH-R Evo, 4 pistons, resin pads
Rotors: TRP R1 223 mm, 6-bolt, 2.3 mm widthShifters
SRAM GX DH
7 spChain guide
E13 LG1 + Bottom Guide
32-34tREAR DERAILLEUR
SRAM GX DH
7 spBottom bracket
SRAM DUB
PressfitCrankset
TRUVATIV Descendant DH, 165 mm crank arms, DUB
Chainring: TRUVATIV Descendant DH X-Sync, 34tChain
KMC X11EL
BlackCassette
E13 DH 7 Speed Integrated Cassette
7 sp, 9-24tRims
E13 GRAPPLER Race Alloy
Rear: 27.5'', 32h, 30 mm inner width - Front: 29'', 32h, 30 mm inner widthHubs
Rear: E13 GRAPPLER Race Alloy - Front: E13 GRAPPLER Race Alloy
Rear: 32h, sealed bearings, 12 x 157 mm, black - Front: 32h, sealed bearings, 20 x 110 mm Boost, blackTyres
Rear: SCHWALBE TACKY CHAN - Front: SCHWALBE TACKY CHAN
Rear: 27.5''x2.4'', Super DH, Addix Ultra Soft, Tubeless Easy - Front: 29"x2.4", Super DH, Addix Ultra Soft, Tubeless EasySeat post
RIDE ALPHA Super Light
31.6 mm, 250 mm, Alloy 7075Saddle
FIZIK Gravita Alpaca X5
130 mm width, S-Alloy railsWeight
18,1 kg / 39,9 lbs
Average weight for S size, without pedals. Weight may differ slightly due to manufacturing tolerances.Pedals included
No
Colour
Clear Silver
Shiny FinishAccessories
Chainstay protector, seatstay protector, downtube protector, roller cover, frame mudguard, tubeless valves, fork fender specific Fox 40
*Please note that bike specs are subject to change without prior notice
Bicycle type
Frame DH Racing
Frame material
Al 6066 T4, T6
Frame weight
5,3 kg / 11,68 lbs in size S with frame protections, chain guide, rear wheel axle
Rear travel
220 mm
Shock length/stroke
250 mm / 75 mm
Piggy back shock compatible
Yes
Shock bushings
30 x 8 mm / 30 x 8 mm
Recommended/max. fork height
612 mm / 620 mm
Headset type
ZS56 / ZS56
Maximum tyre dimension (etrto)
65 mm
Disc brake standard
Postmount 200 mm
Rear rotor max. size
223 mm
Seatpost/seat clamp diameter
31,6 mm / 34,9 mm
Bottom bracket type
Press Fit BB 107
ISCG
ISCG 05
Rear hub compatibility
L=200 mm, M12, P1.0 mm - Hub 157 x 12 mm standard Maxle
Flip Chip
Front / UpWheel Base Length
CenteredBridge
XS & S : Thin - M & L : Medium - XL : Thick



Built for podiums and steep descents, the SUPREME DH V5 Signature pairs a triple-butted Alloy 6066 frame with 220mm of travel and FOX Factory suspension front and rear. TRP DH-R Evo brakes bring fierce stopping power, while the SRAM GX DH drivetrain and E13 chain guide keep gear shifts precise under pressure. Rolling on mixed-size E13 Grappler wheels wrapped in Schwalbe Tacky Chan tyres, this build is ready for anything the trail throws at it—no pedals, no nonsense, all downhill.
Crafted for downhill domination, this DH Racing frame is built from tough-as-nails AL 6066 alloy with 220mm of rear travel and room for piggyback shocks. The geometry is fully dialled with a centred wheelbase, Flip Chip adjustment, and fork height range up to 620mm. Add in a Press Fit BB107, ISCG 05 tabs, 223mm rear rotor clearance, and 65mm tyre room, and you've got a chassis that’s pure muscle—engineered to take hits, corner hard, and come back begging for more.
