Commencal Supreme DH V5 XS Chalk Youth Downhill Bike
Frame
SUPREME DH V5 27'', 220 mm travel
27.5'', Alloy 6066, triple butted tubes, T4, T6. Enduro bearingsShock
ROCKSHOX SuperDeluxe Select R
250 x 75 mm, R damper, DebonAir, rebound, 0 Token neg. 1 Token pos.Fork
ROCKSHOX Boxxer Ultimate, 200 mm travel
27.5", Charger 3 RC2 damper W/ButterCups, DebonAir+ W/ButterCups, HSC, LSC, rebound, Boost (20 x 110 mm), 48 mm offset, 0 TokenHeadset
ACROS ZS56 / ZS56
Alloy cups, sealed bearingsStem
RIDE ALPHA DH 40
40 mm extension, direct mount, 31.8 mmHandlebar
RIDE ALPHA R20
31.8 mm, 740 mm width, 20 mm rise, Alloy 6061Grips
ODI Elite Motion
Soft pro compound, single clamp, blackBrakes
TRP DH-R Evo, 4 pistons, resin pads
Rotors: TRP R1 223/203 mm, 6-bolt, 2.3 mm widthShifters
SRAM PG-720
7 spChain guide
E13 LG1 + Bottom Guide
32-34tREAR DERAILLEUR
SRAM GX DH
7 spBottom bracket
SRAM DUB
PressfitCrankset
TRUVATIV Descendant DH, 165 mm crank arms, DUB
Chainring: TRUVATIV Descendant DH X-Sync, 34tChain
KMC X11EL
BlackCassette
SRAM GX DH
7 sp, 11-25tRims
SPANK Spike Race 33
27.5'', 32h, 28 mm inner width, tubeless readyHubs
Rear: FORMULA DHG-157 - Front: FORMULA DHL-93
Rear: 32h, sealed bearings, 12 x 157 mm, Shimano Hyperglide - Front: 32h, sealed bearings, 20 x 110 mm Boost, blackSpokes/nipples
SAPIM D-Light
J-Bend, 2.0-1.65-2.0mm, double butted, stainless, with Nylok, blackTyres
Rear: MAXXIS DHR II - Front: MAXXIS Assegai
REAR: 27.5" x 2.4", WT, 3C MaxxTerra, Double Down, Tubeless Ready - FRONT: 27.5" x 2.5", WT, 3C MaxxGrip, Double Down, Tubeless ReadySeat post
RIDE ALPHA Super Light
31.6 mm, 250 mm, Alloy 7075Saddle
FIZIK Gravita Alpaca X5
130 mm width, S-Alloy railsWeight
16.8 kg / 37.04 lbs
Average weight for XS size, without pedals. Weight may differ slightly due to manufacturing tolerances.Pedals included
No
Colour
Chalk
Shiny FinishAccessories
Chainstay protector, seatstay protector, fork bumpers, downtube protector, roller cover, frame mudguard, pick-up pad, specific Boxxer fender
*Please note that bike specs are subject to change without prior notice.
Bicycle type
Frame DH Racing
Frame material
AL 6066 T4, T6
Frame weight
5,2 kg / 11,46 lbs in size S with frame protections, chain guide, rear wheel axle 4,2 kg / 9,25 lb (without accessories)
Rear travel
220 mm
Shock length/stroke
250 mm / 75 mm
Piggy back shock compatible
Yes
Shock bushings
30 x 8 mm / 30 x 8 mm
Recommended/max. fork height
612 mm / 620 mm
Headset type
ZS56 / ZS56
Maximum tyre dimension (etrto)
65 mm
Disc brake standard
Postmount 200 mm
Rear rotor max. size
223 mm
Seatpost/seat clamp diameter
31,6 mm / 34,9 mm
Bottom bracket type
Press Fit BB 107
ISCG
ISCG 05
Rear hub compatibility
L=200 mm, M12, P1.0 mm - Hub 157 x 12 mm standard Maxle
Flip Chip
Front / UpWheel Base Length
CenteredBridge
XS & S : Thin - M & L : Medium - XL : Thick


Frame
SUPREME DH V5 27'', 220 mm travel
27.5'', Alloy 6066, triple butted tubes, T4, T6. Enduro bearingsShock
ROCKSHOX SuperDeluxe Select R
250 x 75 mm, R damper, DebonAir, rebound, 0 Token neg. 1 Token pos.Fork
ROCKSHOX Boxxer Ultimate, 200 mm travel
27.5", Charger 3 RC2 damper W/ButterCups, DebonAir+ W/ButterCups, HSC, LSC, rebound, Boost (20 x 110 mm), 48 mm offset, 0 TokenHeadset
ACROS ZS56 / ZS56
Alloy cups, sealed bearingsStem
RIDE ALPHA DH 40
40 mm extension, direct mount, 31.8 mmHandlebar
RIDE ALPHA R20
31.8 mm, 740 mm width, 20 mm rise, Alloy 6061Grips
ODI Elite Motion
Soft pro compound, single clamp, blackBrakes
TRP DH-R Evo, 4 pistons, resin pads
Rotors: TRP R1 223/203 mm, 6-bolt, 2.3 mm widthShifters
SRAM PG-720
7 spChain guide
E13 LG1 + Bottom Guide
32-34tREAR DERAILLEUR
SRAM GX DH
7 spBottom bracket
SRAM DUB
PressfitCrankset
TRUVATIV Descendant DH, 165 mm crank arms, DUB
Chainring: TRUVATIV Descendant DH X-Sync, 34tChain
KMC X11EL
BlackCassette
SRAM GX DH
7 sp, 11-25tRims
SPANK Spike Race 33
27.5'', 32h, 28 mm inner width, tubeless readyHubs
Rear: FORMULA DHG-157 - Front: FORMULA DHL-93
Rear: 32h, sealed bearings, 12 x 157 mm, Shimano Hyperglide - Front: 32h, sealed bearings, 20 x 110 mm Boost, blackSpokes/nipples
SAPIM D-Light
J-Bend, 2.0-1.65-2.0mm, double butted, stainless, with Nylok, blackTyres
Rear: MAXXIS DHR II - Front: MAXXIS Assegai
REAR: 27.5" x 2.4", WT, 3C MaxxTerra, Double Down, Tubeless Ready - FRONT: 27.5" x 2.5", WT, 3C MaxxGrip, Double Down, Tubeless ReadySeat post
RIDE ALPHA Super Light
31.6 mm, 250 mm, Alloy 7075Saddle
FIZIK Gravita Alpaca X5
130 mm width, S-Alloy railsWeight
16.8 kg / 37.04 lbs
Average weight for XS size, without pedals. Weight may differ slightly due to manufacturing tolerances.Pedals included
No
Colour
Chalk
Shiny FinishAccessories
Chainstay protector, seatstay protector, fork bumpers, downtube protector, roller cover, frame mudguard, pick-up pad, specific Boxxer fender
*Please note that bike specs are subject to change without prior notice.
Bicycle type
Frame DH Racing
Frame material
AL 6066 T4, T6
Frame weight
5,2 kg / 11,46 lbs in size S with frame protections, chain guide, rear wheel axle 4,2 kg / 9,25 lb (without accessories)
Rear travel
220 mm
Shock length/stroke
250 mm / 75 mm
Piggy back shock compatible
Yes
Shock bushings
30 x 8 mm / 30 x 8 mm
Recommended/max. fork height
612 mm / 620 mm
Headset type
ZS56 / ZS56
Maximum tyre dimension (etrto)
65 mm
Disc brake standard
Postmount 200 mm
Rear rotor max. size
223 mm
Seatpost/seat clamp diameter
31,6 mm / 34,9 mm
Bottom bracket type
Press Fit BB 107
ISCG
ISCG 05
Rear hub compatibility
L=200 mm, M12, P1.0 mm - Hub 157 x 12 mm standard Maxle
Flip Chip
Front / UpWheel Base Length
CenteredBridge
XS & S : Thin - M & L : Medium - XL : Thick



Here’s your 80-word (approx) spec summary of the SUPREME DH V5 XS in Biker’s Republic style: Built for serious downhill destruction, the SUPREME DH V5 XS rocks a 220mm travel alloy frame, paired with a buttery-smooth RockShox Boxxer Ultimate fork and SuperDeluxe Select R shock. TRP DH-R Evo brakes deliver insane stopping power, while SPANK Race 33 rims and MAXXIS rubber keep you glued to the line. SRAM GX DH 7-speed drivetrain ensures bulletproof shifting. It’s compact, fierce, and ready to send.
The SUPREME DH V5 XS frame is a downhill juggernaut, forged from AL 6066 and built to handle the brutal. With 220mm of rear travel and a 250x75mm shock setup, it's hungry for high-speed hits. Postmount brakes, piggyback shock compatibility, and a 157 x 12 rear hub keep things tight and aggressive. At just over 5kg with armour, it's lean for the punishment it takes. Add a flip chip and centred wheelbase, and you’ve got a frame that laughs at limits.
