Commencal T.E.M.P.O. Power Essential E-Bike
Frame
T.E.M.P.O. POWER, 135 mm travel
29'', Alloy 6066 triple butted tubes, T4, T6. Bolu bearingsMotor
BOSCH Performance Line SX
Max. torque: 55 N.m, 250 WBattery
BOSCH PowerTube 400
Integrated, 400 WhDisplay
BOSCH System Controller
ON/OFF switch, assist mode level, battery charge levelShock
FOX Float Performance
210 x 50 mm, rebound, 2-postion (open/firm) lever, 3-setting open mode tuning range, 0.6 spacersFork
FOX 36 Performance E-Bike, 150 mm
29", Grip damper, rebound, LSR, 3-position compression, Boost (15 x 110 mm), 44 mm offset, 4 spacersHeadset
ACROS ZS56 / ZS56
Alloy cups, sealed & stainless steel bearingsStem
RIDE ALPHA 40
40 mm extension, 31.8 mmHandlebar
RIDE ALPHA R20 760 on S - RIDE ALPHA R27 780 on M / L - RIDE ALPHA R27 800 on XL
31.8 mm, 760 mm width, 20 mm rise, Alloy 6061 on S - 31.8 mm, 780 mm width, 27 mm rise, Alloy 6061 on M / L - 31.8 mm, 800 mm width, 27 mm rise, Alloy 6061 on XLGrips
RIDE ALPHA Mushroom
Soft compound, single clamp, 132 mm width, blackBrakes
SHIMANO Deore, 4 pistons, resin pads
Rotors: SHIMANO SM-RT86 203 mm, 6-boltShifters
SHIMANO Deore
12sChain guide
RIDE ALPHA
32-34 TREAR DERAILLEUR
SHIMANO Deore
12sCrankset
E13 Helix Core e*spec, 155 mm crank arms
Rotors: E13 Helix Race e*spec, 34t, direct mountChain
SHIMANO Deore
12sCassette
SHIMANO Deore
12s, 10-51tRims
DT SWISS H 1900 LS
29'', 28h, 30 mm inner width, Tubeless ReadyHubs
DT SWISS 370
Rear: 28h, 12 x 148 mm, sealed bearings, 18t, e-bike specific, Shimano Hyperglide - Front: 28h, 15 x 110 mm, sealed bearingsSpokes/nipples
DT SWISS Hybrid 1
Straightpull, 2.34 / 2.0 mm, double butted, stainless, with ProLock, blackTyres
Rear: SCHWALBE Tacky Chan - Front: SCHWALBE Magic Mary
Rear: 29"x2.4", Evo, Super Trail, Addix Soft, Tubeless Easy - Front: 29"x2.4", Evo, Super Trail, Addix Ultra Soft, Tubeless EasySeat post
KS Ragei
31.6 mm, 125 mm on S, 170 mm on M, 190 mm on L /XLSaddle
FIZIK Terra Ridon X5
145 mm width, S-Alloy Mobius railsWeight
20,4 kg / 44.97 lbs
Average weight for S size, without pedals. Weight may differ slightly due to manufacturing tolerances.Pedals included
CRANKBROTHERS Stamp 1
Colour
Glittery Black
Shiny FinishAccessories
Down tube protector, chainstay protector, seatstay protector, pedals, Fox 36 specific fender, included with Fidlock bases, down tube plastic film protector
Battery charger: BOSCH 4A Charger. Compact size & lightweight
*Please note that bike specs are subject to change without prior notice.Battery recycling
Partnership with BOSCH
The battery (used up, damaged, defective) must be recycled. Each national distributor is responsible for providing the dealer with a free recycling solution.
Applicable laws: Battery Act, Directive 2006/66/EC, BattG in Germany too.
Robert Bosch GmbH recommends concluding a contract with a national service provider for returning batteries in each case.
Bicycle type
E-BIKE TRAIL 29''
Frame material
AL 6061 / AL 6069
Rear travel
135 mm
Shock length/stroke
210 x 50 mm
Shock bushings
20 x 10 mm - 30 x 10 mm
Recommended/max. fork height
551 mm (44 offset) / 561 mm
Headset dimension
ZS56 / ZS56, Integrated cable routing
Maximum tyre dimension (etrto)
63 mm / Ø756
Disc brake standard
PM 180 mm
Rear rotor max. size
203 mm
Seatpost/seat clamp diameter
31,6 mm / 34,9 mm
Bottom bracket type
BOSCH E-BIKE
ISCG
Yes (BOSCH Standard)
Rear hub compatibility
12 x 148 mm / Maxle stealth 180 mm M12 x 1,0


Frame
T.E.M.P.O. POWER, 135 mm travel
29'', Alloy 6066 triple butted tubes, T4, T6. Bolu bearingsMotor
BOSCH Performance Line SX
Max. torque: 55 N.m, 250 WBattery
BOSCH PowerTube 400
Integrated, 400 WhDisplay
BOSCH System Controller
ON/OFF switch, assist mode level, battery charge levelShock
FOX Float Performance
210 x 50 mm, rebound, 2-postion (open/firm) lever, 3-setting open mode tuning range, 0.6 spacersFork
FOX 36 Performance E-Bike, 150 mm
29", Grip damper, rebound, LSR, 3-position compression, Boost (15 x 110 mm), 44 mm offset, 4 spacersHeadset
ACROS ZS56 / ZS56
Alloy cups, sealed & stainless steel bearingsStem
RIDE ALPHA 40
40 mm extension, 31.8 mmHandlebar
RIDE ALPHA R20 760 on S - RIDE ALPHA R27 780 on M / L - RIDE ALPHA R27 800 on XL
31.8 mm, 760 mm width, 20 mm rise, Alloy 6061 on S - 31.8 mm, 780 mm width, 27 mm rise, Alloy 6061 on M / L - 31.8 mm, 800 mm width, 27 mm rise, Alloy 6061 on XLGrips
RIDE ALPHA Mushroom
Soft compound, single clamp, 132 mm width, blackBrakes
SHIMANO Deore, 4 pistons, resin pads
Rotors: SHIMANO SM-RT86 203 mm, 6-boltShifters
SHIMANO Deore
12sChain guide
RIDE ALPHA
32-34 TREAR DERAILLEUR
SHIMANO Deore
12sCrankset
E13 Helix Core e*spec, 155 mm crank arms
Rotors: E13 Helix Race e*spec, 34t, direct mountChain
SHIMANO Deore
12sCassette
SHIMANO Deore
12s, 10-51tRims
DT SWISS H 1900 LS
29'', 28h, 30 mm inner width, Tubeless ReadyHubs
DT SWISS 370
Rear: 28h, 12 x 148 mm, sealed bearings, 18t, e-bike specific, Shimano Hyperglide - Front: 28h, 15 x 110 mm, sealed bearingsSpokes/nipples
DT SWISS Hybrid 1
Straightpull, 2.34 / 2.0 mm, double butted, stainless, with ProLock, blackTyres
Rear: SCHWALBE Tacky Chan - Front: SCHWALBE Magic Mary
Rear: 29"x2.4", Evo, Super Trail, Addix Soft, Tubeless Easy - Front: 29"x2.4", Evo, Super Trail, Addix Ultra Soft, Tubeless EasySeat post
KS Ragei
31.6 mm, 125 mm on S, 170 mm on M, 190 mm on L /XLSaddle
FIZIK Terra Ridon X5
145 mm width, S-Alloy Mobius railsWeight
20,4 kg / 44.97 lbs
Average weight for S size, without pedals. Weight may differ slightly due to manufacturing tolerances.Pedals included
CRANKBROTHERS Stamp 1
Colour
Glittery Black
Shiny FinishAccessories
Down tube protector, chainstay protector, seatstay protector, pedals, Fox 36 specific fender, included with Fidlock bases, down tube plastic film protector
Battery charger: BOSCH 4A Charger. Compact size & lightweight
*Please note that bike specs are subject to change without prior notice.Battery recycling
Partnership with BOSCH
The battery (used up, damaged, defective) must be recycled. Each national distributor is responsible for providing the dealer with a free recycling solution.
Applicable laws: Battery Act, Directive 2006/66/EC, BattG in Germany too.
Robert Bosch GmbH recommends concluding a contract with a national service provider for returning batteries in each case.
Bicycle type
E-BIKE TRAIL 29''
Frame material
AL 6061 / AL 6069
Rear travel
135 mm
Shock length/stroke
210 x 50 mm
Shock bushings
20 x 10 mm - 30 x 10 mm
Recommended/max. fork height
551 mm (44 offset) / 561 mm
Headset dimension
ZS56 / ZS56, Integrated cable routing
Maximum tyre dimension (etrto)
63 mm / Ø756
Disc brake standard
PM 180 mm
Rear rotor max. size
203 mm
Seatpost/seat clamp diameter
31,6 mm / 34,9 mm
Bottom bracket type
BOSCH E-BIKE
ISCG
Yes (BOSCH Standard)
Rear hub compatibility
12 x 148 mm / Maxle stealth 180 mm M12 x 1,0



The T.E.M.P.O. POWER ESSENTIAL is precision-built for trail riders who want reliable tech without the fluff. A BOSCH SX motor and 400 Wh battery power your ride, while FOX 36 and Float suspension soak up every hit. With SHIMANO Deore 12-speed shifting and 4-piston brakes, it’s all about control. DT SWISS wheels, Schwalbe rubber, and a KS dropper post round out a spec sheet built for serious fun. Rugged, responsive, and ready for NZ’s wildest trails—this bike is all killer, no filler.
Built for the trail but powered for the long haul, this e-bike’s tech is all dialled in. A 135mm rear travel frame in AL 6061/6069 alloy pairs with a 210x50mm shock and Bosch-specific bottom bracket for precise, punchy performance. With integrated cable routing, PM180 brake mounts, and support for up to a 203mm rear rotor, it’s as clean as it is capable. Tidy headset dimensions, ISCG tabs, and stealth Maxle compatibility make this one smooth, trail-hungry machine.
